Unit specification

Take some time to familiarise yourself with our website, there's lots of useful hits, tips and information that will make ordering your kitchen online as simple as possible.

Base unit

1. 18mm MFC rigid kitchen, glue & dowel construction, colour co-ordinated both inside & out, 720mm high (+150mm Legs) as standard.

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. 18mm MFC adjustable shelf.

4. Solid, colour co-ordinated 8mm MFC backs, with a 42mm service void behind.

5. Blum Clip Top Metal 110 degree door hinges with 3-way adjustment and soft close additionally available.

6. Fully adjustable 150mm legs for fitting on uneven floors.

7. Blum Tandembox A Design, twin walled metal sided drawer system with 16mm solid base and metal back incorporating full extension runners with soft close dampers additionally available.

Wall unit

1. 18mm MFC rigid kitchen, glue & dowel construction, colour co-ordinated both inside & out, 575, 720 & 900mm high options available.

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. 2 x 18mm MFC adjustable shelves.

4. Solid, colour co-ordinated 8mm MFC backs in all wall units.

5. Blum Clip Top Metal 110 degree door hinges with 3-way adjustment and soft close additionally available.

6. Concealed wall hanging brackets with 3-way adjustment. Each pair of brackets can carry 70kgs and conforms to DIN68840. Supplied with wall hanging plates.

Corner base unit

1. 18mm MFC rigid kitchen, glue & dowel construction, colour co-ordinated both inside & out.

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. 18mm MFC adjustable shelf.

4. Solid, colour co-ordinated 8mm MFC backs, with a 42mm service void behind.

5. Blum Clip Top Metal 110 degree door hinges with 3-way adjustment and soft close additionally available.

6. Fully adjustable 150mm legs for fitting on uneven floors.

7. 18mm MFC Blanking Panel, 500mm wide on all corner base units.

L-shape corner base unit

1. 18mm MFC rigid kitchen, glue & dowel construction, colour co-ordinated both inside & out.

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. 18mm MFC adjustable shelf.

4. Solid, colour co-ordinated 8 & 18mm MFC backs in L-Shape Corner Base units.

5. Blum Clip Top Metal 170 degree door hinges with 3-way adjustment and soft close additionally available.

6. Fully adjustable 150mm legs for fitting on uneven floors.

Mid height unit

1. 18mm MFC rigid kitchen cabinet, glue & dowel construction, colour co-ordinated both inside & out 1250mm high (+ 150mm Legs).

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. 18mm MFC adjustable shelves (no of shelves depends on unit type).

4. Solid, colour co-ordinated 8mm MFC backs, with a 42mm service void behind.

5. Blum Clip Top Metal 110 degree door hinges with 3-way adjustment and soft close additionally available.

6. Fully adjustable 150mm legs for fitting on uneven floors.

Tall unit

1. 18mm MFC rigid kitchen cabinet, glue & dowel construction, colour co-ordinated both inside & out.1970 & 2150mm high (+150mm Legs).

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. 18mm MFC adjustable shelves (no of shelves depends on unit type).

4. Solid, colour co-ordinated 8mm MFC backs, with a 42mm service void behind.

5. Blum Clip Top Metal 110 degree door hinges with 3-way adjustment and soft close additionally available.

Please note on appliance towers, all top doors measuring 490mm high or less are always top hung as standard.

6. Fully adjustable 150mm legs for fitting on uneven floors.

Tall appliance housing unit

1. 18mm MFC rigid kitchen cabinet, glue & dowel construction, colour co-ordinated both inside & out.1970 & 2150mm high (+150mm Legs).

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. 18mm MFC adjustable shelves (no of shelves depends on unit type).

4. Solid, colour co-ordinated 8mm MFC backs, with a 42mm service void behind.

5. Blum Clip Top Metal 110 degree door hinges with 3-way adjustment and soft close additionally available.

Please note on appliance towers, all top doors measuring 490mm high or less are always top hung as standard.

6. Fully adjustable 150mm legs for fitting on uneven floors.

7. 18mm MFC fixed shelves (no of shelves depends on unit type).

3 Drawer pack

1. 18mm MFC rigid kitchen, glue & dowel construction, colour co-ordinated both inside & out, 720mm high (+150mm Legs) as standard.

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. Fully adjustable 150mm legs for fitting on uneven floors.

4. Solid, colour co-ordinated 8mm MFC backs, with a 42mm service void behind.

5.1. Blum 450mm Tandem.

5.2. Blum 500mm Tandem x 2.

Dresser unit

1. 18mm MFC rigid kitchen, glue & dowel construction, colour co-ordinated both inside & out, 720mm high (+150mm Legs) as standard.

2. Hardwearing colour co-ordinated 2mm thick durable ABS edging.

3. 18mm MFC adjustable shelf.

4. Solid, colour co-ordinated 8mm MFC backs, with a 42mm service void behind.

5. Blum Clip Top Metal 110 degree door hinges with 3-way adjustment and soft close additionally available.

6. Blum 270mm Tandembox.
